Exline's Equipment List

Following is a partial listing of our major equipment. It will identify some of the capabilities we can provide to your company.

Download our full facility and equipment list >





CNC and NC Machining

Cincinatti Horizontal Machining Center
Machine #: 232, Model #: 10 HC

  • X=100″ Y=42″ Z=24″
  • 30 Station auto tool changer
  • 10,000 lb. table capacity
  • 104″ x 31″, 30″ round - 1° indexing rotary table
  • 45 spindle taper

Mori-Seike CNC Bar Feed Lathe
Machine #: 320, Model #: SL-2B

  • 9-1/2″ Diamer
  • 10″ Length
  • 2-1/2" Bar Capacity

Mori-Seike CNC Lathe
Machine #: 330, Model #: SL-3B

  • 9-1/2″ Diamer
  • 21″ Length
  • 1-7/8" Bar Capacity

Mori-Seike CNC Lathe
Machine #: 332, Model #: Frontier Cl.

  • 9-1/2″ Diameter
  • 19-1/2″ Turning Length
  • 1-3/4″ Bar Capacity
  • Collet or Chucker
  • Tailstock
  • 3500 RPM

Mori-Seike CNC Lathe
Machine #: 350, Model #: LL-7B 3500

  • 43″ Diameter
  • 21″ Over Carriage
  • 138" Length
  • 8-1/2″ Bar Capacity

Mori-Seike CNC Lathe
Machine #: 345, Model #: SL-403C

  • 24.4″ Diameter
  • 2481.4″ Length
  • 245.1″ Thru Hole Capacity
  • 24Fanuc 18iTA Control

Citizen Swiss Turn C.N.C. Lathe
Machine #: 360, Model#: A32

  • 1.25" Diameter
  • Double Spindle
  • Live Mill & Drill

Puma 300, L. M. B. Lathe
Machine #: 334

  • 10″ Diameter
  • 52″ Length
  • 3″ Bar Feeder
  • Live Mill & Drill

Puma 10HC CNC Lathe
Machine #: 333

  • 14.5″ Diameter
  • 20″ Length
  • 3″ Bar Capacity
  • Programmable Tailstock
  • 3500 RPM

Hurco Machining Center
Machine #: 337, Model #: VMX40

  • X=40″ Y=20″ Z=22″
  • 24 Station auto tool changer
  • 40 Spindle taper
  • 10,000 RPM spindle

Hitachi Seiki Vertical Machining Center
Machine #: 335, Model #: VK-55

  • X=39″ Y=22″ Z=22″
  • 20″ Diameter
  • 4-axis horizontal rotary table
  • 20 Station auto tool changer
  • CAT 50 spindle taper

Gidings & Lewis 3-Axis Milling Machine
Machine #: 237

  • X=60.5″ Y=73″ Z=35″
  • 26" Quill
  • 30" Air index table
  • 4" Dia. Spindle
  • CAT 50 spindle taper

Bridgeport Mill
Machine #: 322

  • X=18″ Y=12″ Z=5″
  • 16″ Knee travel
  • Boss 5 CNC control

Kia Horizontal Machining Center
Machine #: 336, Model #: KH-63G

  • X=37.4″ Y=32.5″ Z=29.9″
  • 2 each 24.9″ x 24.9″ Pallets
  • 1° indexing, 60 Station auto tool changer
  • CAT 50 Spindle taper

Union Horizontal Boring Mill
Machine #: 236, Model #: BKFP 130

  • X=118″ Y=78″ Z=60″
  • 5.12″ Diameter quill with 30″ travel
  • 63″ x 79″ Rotary table
  • CAT 50 spindle taper
  • 27,500 Lb table capacity

Century Turn, VTC 76"
Machine #: 222

  • 76" Table Diameter
  • 86" Max Swing
  • 20 Ton Table Weight Capacity
  • 60" Max Height Under Rail
  • 90" X axis Travel
  • 60" Z Axis Travel
  • 75 Main Spindle Horsepower
  • Ram 10.5" Octagon
  • 360,000 Position C Axis with a 15 HP Live Spindle

Engine Lathes

Poreba Gap Bed Lathe
Machine #: 201, Model #: TPK 90

  • 25″ Over saddle
  • 36″ Over bed
  • 46.5″ Dia. in gap
  • 15″ Long
  • 16′ 6″ Between Centers
  • 24″ Steady rest
  • 32″ Chuck

American Lathe
Machine #: 202

  • 36″ Diameter
  • 200″ Length

Acelson Lathe
Machine #: 203, Model #: 25x192 A-25

  • 17-1/2″ Swing over carriage
  • 28″ Diameter
  • 192″ Between Centers

Hendey Lathe
Machine #: 206

  • 24″ x 168″

Hendey Lathe
Machine #: 207, Model #: 24 x 120

  • 24″ Diameter
  • 120″ Between Centers
  • 16-3/4″ Over D.R.O. bracket

Clausing/Colchester Lathe
Machine #: 208

  • 12″ Diameter
  • 26″ Between centers
  • 7″ Over carriage
  • 11-1/2″ Over Ways

Monarch Lathe
Machine #: 253

  • 20″ Diameter
  • 72″ Between Centers

Mazak Lathe
Machine #: 216

  • 24″ Diameter
  • 160″ Between Centers
  • 14.9″ Over carriage
  • 25.5″ Over ways
  • 4-1/8″ Bar Capacity

Cincinnati Lathe
Machine #: 218

  • 22″ Diameter
  • 80″ Between Centers

Hwacheon CNC Lathe
Machine #: 219

  • Model: 2017 Mega 100 x 3000
  • 28.34″ Diameter Swing Over Cross Slide
  • 39.37″ Diameter Swing Over Bed
  • 118.11″ and 11,023 lbs. Between Centers
  • 6″ Bar Capacity
  • Fanuc OiT-D Control
  • 7.87" Diameter Tailstock
  • 6.1" - 25" Capacity Steady Rest
  • Chip Conveyor
  • 32" 4 Jaw Chuck

Warner Swasey 5A, 75HP
Machine #: 290

  • 36″ Over ways
  • 33-3/8″ Over carriage
  • 32″ Chuck diameter
  • 12-1/2″ Thru Spindle
  • 7′ 10″ Length
  • Chuck to turret face

Warner Swasey #3
Machine #: 391, Model #: M4630

  • 15-3/″ Diameter over bed
  • 7″ Over cross slide
  • 22″ Length
  • 1-1/2″ Bar capacity

Clausing 15" Lathe
Machine #: 214, Model #: 15-746

  • 15″ Over ways
  • 9″ Over carriage
  • 48″ Between Centers
  • 2-1/8″ Bar capacity

Clausing 17" Lathe
Machine #: 315

  • 17" Over ways
  • 60" Length
  • 3-1/2" Bar capacity

Bullard Vertical Mill
Machine #: 221

  • 70″ Swing
  • 52″ Height
  • 56″ Diameter table

Monarch Engine Lathe
Machine #: 401

  • 28″ Over saddle
  • 37″ Over bed
  • 144″ Between Centers
  • Spindle speeds 10 to 1250 RPM
  • 29″ Steady rest
  • 28″ 4-jaw chuck
  • 3-9/16″ Diameter thru spindle hole

Milling Machines

Sigma Horizontal Mill
Machine #: 225

  • x=29″ y=28-1/2″ z=37-1/2″
  • 32″ x 36″ Table
  • 80″ Bed
  • 2-1/2″ Spindle
  • Power Rotary Table
  • 24″ Head Height
  • 2-1/2″ Spindle quill

Acer E-Mill
Machine #: 226, Model #: EVS-3VKH

  • x=31″ y=13″ Ram=5″

Index Milling Machine
Machine #: 327, Model #: 760

  • x=30″ y=11″ z=20″
  • 5-1/2 Spindle quill travel
  • Universal mill w/ #40 taper horizontal spindle

Lucas Horizontal Mill
Machine #: 238

  • x=59-5/8″ y=55″ z=46-5/8″
  • 72″ x 40″ Table
  • 8′ Bed
  • 4″ Spindle w/ digital readout
  • 36″ Quill

Lucas Horizontal Boring Mill
Machine #: 239

  • x=84″ y=72″ z=96″
  • 5″ Spindle
  • 50 Taper
  • Digital Readout
  • Table weight cap = 25 tons
  • 30 HP Spindle
  • Right angle attachment
  • 48″ x 60″ Air rotary table
  • 36″ Quill

Grinding Machines

Norton Grinder
Machine #: 240

  • 28″ Diameter
  • 96″ - 102"" Length
  • Cylindrical Grinding

Landis-Lund Grinder
Machine #: 241, Model #: HMPB

  • 28″ diameter
  • 100″ - 118″ Length
  • Cylindrical grinder
  • Diamond and Conventional abrasives

Landis Grinder
Machine #: 247

  • 14″ Diameter
  • 36″ Length
  • Cylindrical capabilities
  • Type "C" Plain Grinder

Okamoto Surface Grinder
Machine #: 249, Model #: Accugar - 124N

  • 12″ Width
  • 27″ Length
  • 12.7″ Height
  • 930 Lbs. weight

Churchill ID Grinder
Machine #: 454

  • 11″ - 38″ Inside diameter
  • 60″ Maximum length

Erfurt Cylindrical Grinder
Machine #: 256

  • 12-1/2″ Diameter
  • 78″ Length
  • 660 Lbs. weight
  • Diamond Grinding and conventional abrasives

Churchill Cylindrical Grinder
Machine #: 251

  • 41″ Diameter
  • 125″ Length"

Honing Machines

Barnes Hone
Machine #: 451, Model #: 4014

  • 18″ Diameter
  • 45″ Length

Barnes Hone
Machine #: 455, Model #: 4014

  • 20″ Diameter
  • 58″ Length

Barnes Hone
Machine #: 457, Model #: 4030

  • 22″ Diameter
  • 60″ Length

Diamond Super Finishing Equipment

  • 1-3/8″ - 4-1/2″ Outside Diameter

Polishing Equipment

  • Conventional abrasives and Diamond Belt

Crankshaft Journal



Undersizing Machines



2-Ton Bridge Cranes

  • 2 Cranes

Plasma & Flame Spray Equipment Thermal Spray Capabilities

Combustion -- Wire

  • Inside & outside diameters
  • Metco models K, 5K, 10E, 12E, 14E
  • 24″ Extensions

Combustion -- Powder

  • Metco 5PII

Combustion - High Velocity Oxy-Fuel (HVOF)
Machine #: 252

  • Jet Kote II Hydrogen & propylene

Machine #: 250

  • DJ1000 w/ ID extension propane

Wire Arc
Model #: TAFA/TAFA 8850

  • 8830 with 36″ Extension

Plasma Arc
Machine #: 242

  • Metco 7M with 9M conversion; 80 KW
  • Metco MN w/ 3M Gun; 40 KW
  • Metco 3MBT w/ 24"" Extension
  • Metco 4MP Powder Feeders

Spray Stations
Machine #: 212

  • 41″ Diameter
  • 204″ Length

Machine #: 243

  • 36″ Diameter
  • 168″ Length

Machine #: 253

  • 26″ Diameter
  • 88″ Length

Machine #: 244

  • 90″ Diameter
  • Adjustable length

Accoustical Spray Booth



Portable Vacu-Blast System



Cleaning & Surface Protection

Blast Room

  • Chilled iron grit
  • 12′ Length x 15″ Width x 9' Height
  • A2 Utility Pressure Blast
  • Blasting 3 ea. A2 Utility

Blast Cabinet

  • 3 different cabinets
  • Pangborn 36"" x 60"" Suction blast
  • Empire 36"" x 48"" Pressure blast
  • Glass bend cleaning
  • Shot Peeing - Aluminum Oxide

Acid Cleaning Tank
Machine #: 494

  • 6″ x 6″ x 7″
  • 1500 Gallons

Hot Dip Caustic Cleaning Tank

  • 2 tanks
  • 7′ x 6′ x 7″
  • 1500 Gallons

Malsbary Steam Cleaning Unit
Model #: 250



Miscellaneous

Barrett Boring Bar
Machine #: 234

  • 24″ Centerline Height
  • 5″ Diameter bar
  • 60″ Stroke
  • 10′ Maximum part length

American Hoffman Electronic Balancer
Machine #: 229

  • 40″ Diameter
  • 90″ Length
  • .78″ - 4.5″ Journal Diameter
  • 125-3900 RPM Speed Range
  • 2000 Lbs maximum weight

300 Ton Horizontal Press
Machine #: 260

  • 15′ 6″ Length
  • 46″ Between press bars

Mitts & Merrill Keyseater #3A
Machine #: 230

  • 1/8″ - 2-1/2″ Wide x 24″ Long
  • Internal keyways

Vertical Shaft Straightener Press
Machine #: 259

  • 150 Ton
  • 10″ Diameter
  • 20″ + Length

Vertical Press
Machine #: 261

  • 48″ Between rails
  • 25″ Ram to rails

Summit Radial Arm Drill Press
Machine #: 270

  • 6′ Arm
  • 14-1/2″ Column

Burgmeister 6 Spin Drill
Machine #: 371

  • 12″ Work height
  • 6″ Quill travel

Kalamazoo Vertical Band Saw
Machine #: 280

  • 12″ Capacity
  • 36″ Throat

Autosaw
Machine #: 295, Model #: 10

  • 10" Diameter

DoAll Saw
Machine #: 340, Model #: C-305A

  • 12″ Diameter
  • Auto feed up to 60″ Length

Sauder Furnace
Machine #: 284

  • 10′ x 14′ x 10′
  • 40,000 Lbs
  • Digital Control Programmer
  • 600° - 1300°

Metal Muncher
Machine #: 285

  • 3/8″ Thick Max
  • 36″ Break Length
  • 18″ Shear

Sunbeam Furnace



Magnaflux Machine



Ultra Sonic



Dye Penetrant



White Line



Welding Machines

  • Lincoln 300 AMP TIG
  • Miller CP 250 MIG
  • Miller Stick
  • Lincoln Wire
  • Tri Mark
  • 3 TIG Welders
  • Plasma welder for TIG welder
  • Plasma cutter

Bridge Cranes

  • 8 each
  • Up to 15 ton capacity

Computerized Job Control & Tracking System



Computer Aided Drafting Department



Datacut Grafx II NC/CAD/CAM Programming System



Research & Development Department



Granite Surface Plating

  • 36" x 48

Mitutoyo CMM
Model #: BRT 710-manual 2001

  • Granite table: 35.44″ x 63.78″
  • 26.85″ Maximum part height
  • x=28″ y=40″ z=24″

PORTABLE FIELD EQUIPMENT

Journal Machines

  • 6″ - 12″ Diameters

Journal Squirrel Machine

  • 6″ - 11″ Diameters
  • 11″ Maximum Journal Length

Large Portable Key Cutter

  • Flat milling and cutting keyways 3-1/4″ wide and 9-1/2″ long on both straight and tapered shafts

Small Portable Key Cutter

  • Cutting 1/4″ - 1″ wide on both straight and tapered shafts

Line Boring Bars

  • 2-1/2″ - 6″ Diameter
  • Boring for main bearing saddle assemblies of any diameter and bedplate length

Portable Milling Machines

  • Boring for up to 5' length

Universal Boring Equipment

  • Boring for up to 28" diameter

Universal Boring Bar

  • Compressor cylinders up to 24" diameter

Portable Valve Seat Cutting Machines

  • Cutting different sizes and forms of seats

Crankshaft Straightening & Polishing Equipment

  • Crankshafts up to 17" diameter

Large Flange Facing Machine

  • Face flanges from 14" - 40" diameter

Small Flange Facing Machine

  • Face flanges from 3" - 13" diameter



Find an Exline Rep

Request a Quote



Image of Rick Spurlock

Rick Spurlock

Manager of North & Mid-Atlantic Regions

Office: (800) 255-0111

Fax: (785) 826-4425

Cell: (785) 452-1207

r.spurlock@exline-inc.com

Image of Rick Spurlock

Rick Spurlock

Manager of North & Mid-Atlantic Regions

Office: (800) 255-0111

Fax: (785) 826-4425

Cell: (785) 452-1207

r.spurlock@exline-inc.com

Image of Rick Spurlock

Rick Spurlock

Manager of North & Mid-Atlantic Regions

Office: (800) 255-0111

Fax: (785) 826-4425

Cell: (785) 452-1207

r.spurlock@exline-inc.com

Image of Rick Spurlock

Rick Spurlock

Manager of North & Mid-Atlantic Regions

Office: (800) 255-0111

Fax: (785) 826-4425

Cell: (785) 452-1207

r.spurlock@exline-inc.com

Join Our Email List




I am interested in the following information:*
